Gear Train for 2004 Jeep Grand Cherokee
No.
Part # / Description / Price
Price
N/A
Output Shaft Thrust Washer
Mopar
Mopar Notes: Transmissions: 4-SPD. AUTOMATIC 42RE TRANSMISSION.
Description: Green .083
N/A
Transmission Front Clutch Retainer And Bushing 1 Mopar
Mopar Notes: Transmissions: 4-SPD. AUTOMATIC 42RE TRANSMISSION.
Description: NONE
N/A
Rear Clutch Snap Ring Mopar
Mopar Notes: Transmissions: 4-SPD. AUTOMATIC 42RE TRANSMISSION.
Description: .107
N/A
Rear Clutch Snap Ring Mopar
Mopar Notes: Transmissions: 4-SPD. AUTOMATIC 42RE TRANSMISSION.
Description: .095
N/A
N/A
Rear Clutch Snap Ring Mopar
Mopar Notes: Transmissions: 4-SPD. AUTOMATIC 42RE TRANSMISSION.
Description: .098
N/A
Output Shaft Thrust Washer Mopar
Mopar Notes: Transmissions: 4-SPD. AUTOMATIC 42RE TRANSMISSION.
Description: Red .068. Intermediate Shaft, Thrust, w/ 3 Point Bronze Face, .068" Thk.
N/A
Check Ball Mopar
Mopar Notes: Transmissions: 4-SPD. AUTOMATIC 42RE TRANSMISSION.
Description: Dia-.187. Transmission Overdrive Clutch Piston Check Valve
N/A
Rear Clutch Snap Ring Mopar
Mopar Notes: Transmissions: 4-SPD. AUTOMATIC 42RE TRANSMISSION.
Description: .076
3
5
6
10
Transmission Front Clutch Piston Spring Retainer Mopar
Mopar Notes: Transmissions: 4-SPD. AUTOMATIC 42RE TRANSMISSION.
15
16
Clutch Separator Plate Mopar
Mopar Notes: Transmissions: 4-SPD. AUTOMATIC 42RE TRANSMISSION.
Description: With [V] Notch
17
20
Output Shaft Thrust Washer Mopar
Mopar Notes: Transmissions: 4-SPD. AUTOMATIC 42RE TRANSMISSION.
Description: Gray .052
23
Rear Clutch Seal Mopar
Mopar Notes: Transmissions: 4-SPD. AUTOMATIC 42RE TRANSMISSION.
Description: 1.50 ODx.009 Thk
24
Front Clutch Thrust Washer Mopar
Mopar Notes: Transmissions: 4-SPD. AUTOMATIC 42RE TRANSMISSION.
Description: .060`` Thick
25
Transmission Ring Mopar
Mopar Notes: Transmissions: 4-SPD. AUTOMATIC 42RE TRANSMISSION.
Description: INPUT SHAFT
28
34
Clutch Separator Plate Mopar
Mopar Notes: Transmissions: 4-SPD. AUTOMATIC 42RE TRANSMISSION.
Description: Without [V] Notch
37
37
41
Rear Clutch Piston Seal, Inner Mopar
Mopar Notes: Transmissions: 4-SPD. AUTOMATIC 42RE TRANSMISSION.
Description: ~
1 This price excludes a refundable manufacturer's core charge. Add the part to your cart to see the core charge.
No.
Part # / Description / Price
Price
N/A
N/A
Output Shaft Snap Ring Mopar
Mopar Notes: Transmissions: 4-SPD. AUTOMATIC 42RE TRANSMISSION.
Description: 1.029 OD
5
Annulus Gear Snap Ring Mopar
Mopar Notes: Transmissions: 4-SPD. AUTOMATIC 42RE TRANSMISSION.
Description: 1.375 ID
6
8
9
15
17
Sun Gear Shell Snap Ring Mopar
Mopar Notes: Transmissions: 4-SPD. AUTOMATIC 42RE TRANSMISSION.
Description: ~
21
25
28
Hex Flange Head Screw Mopar
Mopar Notes: Transmissions: 4-SPD. AUTOMATIC 42RE TRANSMISSION.
Description: .25-28x.875
29
Transmission Overdrive Clutch Piston Retainer Mopar
Mopar Notes: Transmissions: 4-SPD. AUTOMATIC 42RE TRANSMISSION.
30
Transmission Module Plate Mopar
Mopar Notes: Transmissions: 4-SPD. AUTOMATIC 42RE TRANSMISSION.
Description: Intermediate Shaft, Thrust .060" Thick
No.
Part # / Description / Price
Price
3
Output Shaft Mopar
Mopar Notes: Transmissions: 4-SPD. AUTOMATIC 42RE TRANSMISSION.
Description: Shaft and Bushings
4
Output Shaft Bearing Mopar
Mopar Notes: Transmissions: 4-SPD. AUTOMATIC 42RE TRANSMISSION.
Description: Front.
6
Output Shaft Snap Ring Mopar
Mopar Notes: Transmissions: 4-SPD. AUTOMATIC 42RE TRANSMISSION.
Description: 1.029 OD
